Description
Detail Information
Place of Origin:
Guangdong, China
Output Power:
6000W
Laser Wavelength:
1080
Weight:
500 KG
Laser Power:
1500W/2000W/3000W/4000W/6000W
Welding Speed:
10-100mm/s
Position Accuracy:
±0.05mm
Regulating Frequency:
30-5KHZ
Adjustable Power Range:
10-100%
Repositioning Accuracy:
±0.01mm
Rapid Positioning Accuracy:
1000mm/sec(XYaxis)、500mm/sec(Zaxis)
Beam Quality:
<1.4㎡
Power Stability:
≦3%
Laser Focusing Focal Length:
F=180mm
Maximum Machining Size:
800*600mm/1000*800
Overall Dimension:
L1343xW1454xH22235mm
Highlight:
6000W Output Power Battery Laser Welding Machine
,
1080 Wavelength Laser Welding Equipment
,
3 Years Warranty Fiber Laser Welding Machine
Product Description
Fully Automatic Metal Laser Welding Machine
This high-performance fiber laser welding machine integrates key components including fiber optic continuous laser, gantry motion structure, high-power mirror welding head, water cooling system, and PC control system. Capable of welding any planar geometric shape trajectory (points, lines, circles), it delivers exceptional performance for lithium battery welding applications.
Key Features:
- Advanced fiber laser source optimized for high reflective materials (aluminum)
- Gantry machine tool design with superior rigidity and stability
- High beam quality with excellent stability and low operating costs
- Precision guide rail transmission with high-response servo motors
- Fine welding spots with high melting depth and minimal heat affected zone
- PC industrial computer with user-friendly CNC programming system
- Adjustable laser power with low energy consumption
- Optional CCD visual positioning and automatic focal length measurement
Technical Specifications:
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Laser power | 1500W-6000W | Welding speed | 10-100mm/s |
| Position accuracy | ±0.05mm | Laser Wavelength | 1080 |
| Regulating frequency | 30-5KHZ | Adjustable power range | 10-100% |
| Repositioning Accuracy | ±0.01mm | Rapid positioning speed | 1000mm/sec (XY), 500mm/sec (Z) |
| Coolant system | External water cooling | Operating mode | Continuous/Modulation |
| Beam Quality | <1.4㎡ | Power stability | ≦3% |
| Maximum machining size | 800×600mm or 1000×800mm | Overall Power Consumption | 3.5KW-10KW |
| Dimensions | 1343×1454×22235mm | Machine weight | ≈500KG |
Product Gallery:
Frequently Asked Questions
Q: How do I choose the right model for my needs?
A: Please provide your battery model/type and welding material/thickness. Our experienced team will recommend the optimal configuration.
Q: What support is provided for machine installation?
A: We provide detailed training videos and manuals with each machine. 95% of customers successfully complete installation without additional support.
Q: Is there a minimum order quantity?
A: No MOQ – we support orders from single units to large volume purchases.
Q: How is quality controlled?
A: Each unit undergoes 20+ rigorous tests, including final welding performance verification by our QC team.
Q: What if I encounter technical issues?
A: Contact us immediately – our technical team guarantees response within 24 hours to resolve any problems.
